Miscellaneous
Alternating current
Total output:
1+
Total power that can be supplied to the individual auxiliary sockets must not
2+
3+ exceed the total power (here 660 VA, also 1000 VA and 1600 VA)
x =
max. 660 VA
Total load rating (basic frame)
150 kg
330 LB
max. total load rating (= total of all load ratings of mounted system components)
Max. Load
50 kg
Load rating (system components)
110 LB
(here 50 kg / 110 lbs, also available with other load ratings)
Max. Load
Adjustment of the clamping force (tilt and swivel unit)
Set load:
Describes the load range and also the direction of rotation for setting them
(3-10 kg and 8-14 kg).
Operating position:
This symbol describes the permitted operating positions (right / left) and indicates a prevailing
danger of tilting when changing over.
46
Risk of tilting:
It is imperative to observe the sequence of loading and unloading mobile
equipment carts.
