Assembly
2.6

Load capacity

Although all precautionary measures have been observed to guarantee maximum stability for
this product, it is important to pay attention to unevenness in floors, lift door frames, cables, etc.
in order to prevent accidents.
The monitor should be removed during transport and moved separately in order to ensure
stability during transport.
It is not permissible to exceed the load rating of the uni-cart, pro-cart, duo-cart, compact-cart,
classic-cart or endo-cart carrier system.
You should observe the maximum load capacity of the uni-cart, pro-cart, duo-cart, compact-cart,
classic-cart or endo-cart carrier system (see section 10 of these operating instructions).
2.7

Assembly / Handling

2.7.1 Shelves
Shelves can be removed or installed in another position. Loosen the screws, reposition the shelf
and then screw the shelf tightly in position again. Check the safety-earth resistance.
2.7.2 Drawers
Drawer unit blocks (compact-cart, pro-cart) are provided with a
latch mechanism.
The latch (compact-cart) must be pushed simultaneously in
order to open the drawer.
With pro-cart, the snatch on the front panel has to be lifted.
front trim. Insert drawer during transport (except pro-cart). The drawers can be lifted out in the extended position. A label strip can be affixed to the
2.7.3 The isolating transformer
The isolating transformer is mounted in a housing under the base of the basic frame.
This is assembled at the factory.
2.8

Additional mounting of system components

Additional mounting of ITD system components should only be executed by specialised staff.
A test on tilt stability is, subsequently, to be implemented (see chapter 2.4).
