MOTOR 1 operating time increase
N.B.: parameter visible only if encoder is disabled
Additional time (in seconds) added to the operation time programmed during the acquisition phase.
It is NOT necessary to repeat the travel acquisition.
MOTOR 2 operating time increase
N.B.: parameter visible only if encoder is disabled
Additional time (in seconds) added to the operation time programmed during the acquisition phase.
It is NOT necessary to repeat the travel acquisition.
from 0 to 10 s of manoeuvre.
Enable double manoeuvre time
Enabling this parameter is recommended for installations with particularly long operating times. N.B.:
parameter visible only if encoder is disabled
Disabled.
Enabled.
Adjusting opening delay of MOTOR 2
During opening, MOTOR 2 starts with an adjustable delay after MOTOR 1.
From 0 to 10 s.
Adjusting closing delay of MOTOR 1
During closing, MOTOR 1 starts with an adjustable delay after MOTOR 2.
From 0 to 60 s.
Setting reverse time after activation of sensing edge or obstacle detection (crush
prevention)
This sets the reverse manoeuvre time after activation of the sensing edge or the obstacle detection
system.
From 0 to 60 s.
Set electric lock activation lead time
Sets the electric lock activation time before any manoeuvre.
From 0 to 2 s.
Enable electric lock
Sets duration of electric lock activation time.
Disabled.
Enabled, with time from 1 to 6 s.
This parameter must be set to a value higher than parameter
Disabled.
control unit when powered by a generator and optimise motor control.
Set motor torque during open/close manoeuvre
This parameter must always be equal to or less than the value set for parameter
4 = minimum motor torque ... 8 = maximum motor torque.
Set motor torque during deceleration
4 = minimum motor torque ... 8 = maximum motor torque.
Set motor torque boost at start of manoeuvre
1 = minimum motor torque ... 8 = maximum motor torque.
68
.
.
.
(if enabled).
.
