Connecting components with HDMI jacks

We recommend that you connect components to
the unit using an HDMI cable.
With HDMI, you can easily enjoy both high
quality sound and high quality images.
However, it is necessary to connect the audio
output of the TV to the audio input of the unit
using an optical cable or an audio cord in
Audio/video signal
SAT IN
A
OUTPUT
Satellite tuner
A HDMI cable (not supplied)
B Optical cable (supplied)
C Audio cord (not supplied)
TV monitor, projector, etc.
INPUT
A
HDMI ANTENNA
FM 75
TV OUT
BD/DVD IN COAXIAL
A
Audio/video
signal
Blu-ray Disc player (recorder), DVD
player (recorder), "PlayStation 3"
order listen to the TV's sound from the unit.
For details on the Control for HDMI function,
see ""BRAVIA" Sync Features" (page 27).
Connect the AC power cord (mains lead) after
you have finished connecting all components to
the unit.
Audio signal
OUTPUT
or
C
DMPORT LINE TV
L L
R R
DC 5V
0.7A MAX
ANALOG IN
OUTPUT
Audio/video
signal
: Signal flow
OUTPUT
B
TV SAT SUB WOOFER
OUT
COAXIAL
OPTICAL OPTICAL OPTICAL
DIGITAL IN
BD/DVD
continued
