Avoid spillage. Prior to replacing the fuel cap,
clean and inspect the gasket.
Immediately replace the fuel cap and hand tighten.
■
Wipe up any fuel spillage. Move 9m away from
refueling site before starting engine.
NOTE: It is normal for smoke to be emitted from a
new engine during first use.
WARNING
Always shut off engine before fueling. Never add
fuel to a machine with a running or hot engine.
Move at least 9 m from refueling site before
starting engine. Do not smoke!
1 litre + 20 ml
2 litres + 40 ml
3 litres + 60 ml
4 litres + 80 ml
5 litres + 100 ml

CHARGING THE BATTERY PACK

The battery pack for this tool has been shipped in a low
charge condition to prevent possible problems. Therefore,
you should charge overnight prior to use.
NOTE: Batteries will not reach full charge the first
time they are charged. Allow several cycles (operation
followed by recharging) for them to become fully charged.
Charge battery pack only with the charging assembly
■
provided (BPH-1215 / 12V Ni-Cd).
Make sure power supply is normal household voltage,
■
220V~ to 240V~, 50 Hz.
Connect charger to power supply.
■
Place battery pack in charging stand. Align raised rib
■
on battery pack with groove in charging stand. See
Figure 7.
Press down on battery pack to be sure contacts
■
on battery pack engage properly with contacts in
charging stand.
The charge indicator light (LED), located on the
■
charging stand, will light up red and glow when the
charger is properly connected to power supply. This
light indicates the charger is operating properly. It will
remain on until battery pack is removed from charging
stand or charger is disconnected from power supply.
After normal usage, 3 hours or less of charging time
■
is required to fully recharge battery pack.
If both red and orange LED indicators glow, the
■
battery pack is deeply or completely discharged, and
RBL30BPT V1.indd 14 RBL30BPT V1.indd 14
NL SV DA NO FI EL HU CS RU
English
NOTE: If charger does not charge battery pack or orange
LED continues to glow after more than 30 minutes of
charging, return battery pack and charging assembly
to your nearest Ryobi Authorised Service Centre for
electrical check.
■
■
■

STARTING AND STOPPING

See Figures 9 - 11.
When starting the product for the fi rst time or when the
=
}
battery voltage is low, it may be necessary to manually
=
start this product.
= 50:1
=
= FOR ELECTRIC START:
To start a cold engine:
DO NOT engage the throttle until the engine starts and
runs.
■
■
■
■
■
NOTE: Engaging and releasing the throttle releases the start
lever to the RUN position.
To start a warm engine:
■
To stop the engine:
■
FOR MANUAL
To start a cold engine:
DO NOT engage the throttle until the engine starts and
runs.
■
14
RO PL SL HR TR
6 hours or longer of charging time is required to fully
recharge battery pack.
The battery pack will become slightly warm to the
touch while charging. This is normal and does not
indicate a problem.
Do not place charger in an area of extreme heat or
cold. It will work best at normal room temperature.
When batteries become fully charged, unplug charger
from power supply and remove the battery pack.
Lay the product on a fl at, bare surface.
PRIME - Press the primer bulb 7 times.
SET the start lever to the START position.
PRESS the safety switch (mounted on the auxilary
handle on the tubes) and the ignition switch (mounted
on the arm) at the same time.
Wait 6-10 seconds, then push the throttle to run.
PRESS the safety switch (mounted on the auxilary
handle on the tubes) and the ignition switch (mounted
on the arm) at the same time.
Press and hold the switch in the stop "O" position
until the engine stops.
START:
Lay the product on a fl at, bare surface.
