accessories not recommended for use with this
tool. Any such alteration or modification is misuse
and could result in a hazardous condition leading to
possible serious personal injury.
NOTE: Read and remove all hang tags and store with your
Operator's Manual.
WARNING
Stop the engine and disconnect the spark plug wire
before installing parts, making adjustments, cleaning,
or when not in use. Failure to do so could result in
possible serious personal injury.
ASSEMBLING THE BLOWER TUBES
See Figures 3 - 5.
Place a tube clamp in the groove on elbow and
■
install the elbow tube onto blower. Tighten large
clamp securely.
Place clamp in the groove on the bellows and install
■
the bellows onto the elbow. Tighten clamp securely.
Insert upper tube into adjustable handle. Position the
■
adjustable handle in the center of upper tube and
tighten thumb screw securely.
NOTE: The position of the adjustable handle may
be moved for the best comfort after the blower is
strapped onto the operator's back.
Place clamp in the groove on the bottom end of the
■
bellows and install the upper tube onto the bellows.
Tighten clamp securely.
Join the lower tube and nozzle together by aligning
■
raised locking tabs on lower tube with the raised locking
slots on nozzle and twist to secure.
Assemble the connected lower tube and nozzle to the
■
upper tubes by aligning raised locking tabs on the upper
tube with the raised locking slots on connected lower
tubes by twisting to secure.
NOTE: Check all locking connections to ensure they
are tightly secured.
CAUTION
Make all adjustments to the harness straps before
starting the blower to avoid the possibility of injury.
ADJUSTING HARNESS AND WAIST STRAPS
Straps should be adjusted to a comfortable position before
starting the blower.
To adjust harness strap assembly:
Blower should be in operating position before adjusting
■
the harness straps. Slip arm through harness strap and
onto shoulder, then repeat for the other shoulder.
There are three possible height adjustment positions
■
that can be used to easily adjust harness.
Slip top buckle of harness from adjustment slot and
■
RBL30BPT V1.indd 13 RBL30BPT V1.indd 13
NL SV DA NO FI EL HU CS RU
English
■
■
To adjust waist strap assembly:
■
ADJUSTING ADJUSTABLE HANDLE
See Figure 6.
■
■
MIXING THE FUEL (Fig. 3)
■
■
■
■
■
■
■

FILLING THE TANK

■
■
■
13
RO PL SL HR TR
position to desired height location.
Tighten (pull down on strap) or loosen (lift up on tab of
strap buckle) each harness strap as needed, until each
is adjusted to a comfortable operating position.
Chest strap should be tightened or loosened until
adjusted to a comfortable operating position.
Waist strap should be tightened or loosened until
adjusted to a comfortable operating position.
Loosen thumb screw by twisting counterclockwise.
Move adjustable handle to desired position and secure
screw by twisting clockwise.
OPERATION
WARNING
Petrol is extremely flammable and explosive.
A fire or explosion from gasoline will burn you and
others.
This product is powered by a 2-stroke engine and requires
premixing petrol and 2-stroke oil. Pre-mix unleaded petrol
and 2-stroke engine oil in a clean container approved for
petrol.
This engine is certified to operate on unleaded petrol
intended for automotive use with an octane rating of 87 ([R
+ M] / 2) or higher.
Do not use any type of pre-mixed petrol/oil from fuel
service stations, this includes the pre-mixed petrol/oil
intended for use in mopeds, motorcycles, etc.
Use synthetic 2-stroke oil only. Do not use automotive oil
or 2-stroke outboard oil.
Mix 2% synthetic 2-stroke oil into the petrol. This is a 50:1
ratio.
Mix the fuel thoroughly and also each time before fueling.
Mix in small quantities. Do not mix quantities larger
than usable in a 30 day period. A synthetic 2-stroke oil
containing a fuel stabiliser is recommended.
Clean the surface around the fuel cap to prevent
contamination.
Loosen the fuel cap slowly to release pressure and to
keep fuel from escaping around the cap.
Carefully pour the fuel mixture into the tank.
