SERVICE
Servicing requires extreme care and knowledge and
should be performed only by a qualified service technician.
For service we suggest you return the product to your
nearest AUTHORIZED SERVICE CENTER for repair. When
servicing, use only identical replacement parts.
WARNING
To avoid serious personal injury, do not attempt
to use this product until you read thoroughly and
understand completely the operator's manual. Save
this operator's manual and review frequently for
continuing safe operation and instructing others who
may use this product.
SAVE THESE INSTRUCTIONS.
FEATURES
Weight ............................................................................ 7.8 kg
Engine displacement ....................................................... 30 cc
Air Velocity ................................................................. 290 km/h
Air volume .................................................................10 m
Sound power level ...................................................109 dB(A)
Sound pressure level .................................................93 dB(A)
Maximum engine performance ....................................0.65 kw
Maximum rotational frequency of the engine ...........8500 rpm
Engine speed at idling .................................. 2800 ~ 3600 rpm
Fuel consumption at max. engine performance ...... 0.46 L /h
Fuel tank volume ............................................................ 0.25 L
Battery Voltage .............................................................. 12 Volt
DESCRIPTION
Fig. 1
1 Ignition switch
2 Throttle
3 Throttle arm
4 Start lever
5 Adjustable harness and waist straps
6 12 Volt battery
7 Mesh backing
8 Nozzle
9 Lower tube
10 Upper tube
11 High velocity nozzle with leaf scraper
12 Saftey switch
Fig. 2
13 Primer bulb
14 Recoil starter
15 Fuel cap
16 Engine
RBL30BPT V1.indd 12 RBL30BPT V1.indd 12
NL SV DA NO FI EL HU CS RU
English
Fig. 3
17 Blower housing
18 Elbow
19 Tube clamps
20 Adjustable Handle
21 Bellows
Fig. 4
22 Throttle arm
Fig. 5
23 Upper tube
24 Lower tube
25 Nozzle
Fig. 6
26 Thumb screw
27 Adjustable handle
Fig. 7
28 Red LED
29 Orange LED
3 /min
Fig. 8
30 Battery port
31 Battery
32 Latches
Fig. 9
33 Ignition switch
34 Throttle
35. Lock
Fig. 10
36 Primer bulb
37 Recoil starter
Fig. 11
38 Starter lever
12
RO PL SL HR TR
ASSEMBLY
WARNING
Use metal clamps to secure the tubes after mounting.
Never remove any tube during operation. Failure to
do so could result in serious personal injury.
WARNING
If any parts are missing do not operate this tool until
the missing parts are replaced. Failure to do so could
result in possible serious personal injury.
WARNING
Do not attempt to modify this tool or create
ET LT LV SK BG
