OBJ_BUCH-610-001.book Page 7 Thursday, January 31, 2008 1:43 PM
Maximum Steel Sheet Cutting Capacity
The maximum steel sheet cutting capacity d
depends on the strength properties of the mate-
rial to be cut.
The machine allows for cutting of metal sheet to
the following thicknesses:
Material
Max. strength
property
2
[N/mm
Steel
400
600
800
Aluminum
200
Adjusting Cutter Clearance a
The cutter clearance a (gap be-
tween the cutters) depends on
the sheet thickness d
a
d
Cutter clearance a
max
[mm]
[mm]
0.2 – 1.4
0.3
1.5 – 2.8
0.5
For softer or more ductile materials, the clear-
ance a must be decreased; for harder or more
brittle materials, increased.
Loosen the fastening screw 12 for the bottom
cutter. Adjust the requested cutter clearance a
with the adjustment screw 11. The upper cutter
7 and the bottom cutter 9 may not touch each
other. Check the clearance with the setting gage
13. Retighten the fastening screw 12 for the bot-
tom cutter.
Bosch Power Tools
All manuals and user guides at all-guides.com
Adjusting Cutter Clearance b
max
b
d
max
[mm]
]
Screw the adjustment screw for the upper cutter
2.8
5 in clockwise direction using a fitting pin. Loos-
2.2
en the fastening screw for the upper cutter 8 and
1.9
adjust the upper cutter 7 in such a manner that
the vertical clearance b between upper and bot-
3.5
tom cutter is 0.4 mm. Check the clearance with
the setting gage 13.
Retighten the fastening screw 8 for the upper
cutter. Screw the adjustment screw for the upper
cutter 5 in counterclockwise direction until it
to be cut.
max
faces against the upper cutter 7.
For softer or more ductile materials, the clear-
ance b must be decreased; for harder or more
brittle materials, increased.

Maintenance and Service

Maintenance and Cleaning

Replacing the Bottom Cutter (see figure B)
Unscrew the adjustment screw 11 of the bottom
cutter. Fully unscrew the fastening screw 12 of the
bottom cutter and remove the bottom cutter 9.
Insert a new bottom cutter 9 into the recess of
the cutting base 10. Fasten the bottom cutter
with the fastening screw 12.
Check the cutter clearance a (see "Adjusting
Cutter Clearance a", page 7).
For adjustment of cutter
clearance b, the stroke mech-
anism of the upper cutter
must be at the upper dead
center point. For this, briefly
switch the power tool on and
then immediately off again.
Repeat the procedure again,
as required.
Before any work on the power tool itself,
pull the mains plug.
For safe and proper working, always keep the
power tool and the ventilation slots clean.
1 609 929 N57 | (31.1.08)
English | 7
