Tandberg SLR Installation and User's Guide
SCSI-bus Termination - Internal
Tape Drives
Termination in General
A SCSI-bus is susceptible to interference, such as noise from
electrical motors and other electromagnetic devices. Also due
to the speed of the data on the SCSI-bus, it is of outmost
importance to terminate the SCSI-bus properly. "Termination" is
used to define the ends of the SCSI-bus.
Tandberg SLR2
Will your new tape drive be the last or only SCSI device on a SCSI
cable?
• If your drive will be the last device on
SCSI termination
where the tape
drive is the last or
only SCSI device.
• If your tape drive will be in the middle of
SCSI termination
in a system with
three internal
SCSI devices.
®
SLR5
the SCSI cable or the only device on the
cable, as shown to the left, make sure
that the SCSI termination packs are
installed in the drive (Factory default).
a SCSI chain, as shown to the left, you
must disable SCSI termination on the
drive. To disable SCSI termination on
the tape drive, remove the termination
resistor packs from the drive (see figure
on the following page). Make sure that
the last SCSI device on the cable has
termination enabled.
