Assembly compatibility and operational safety

The saddles of the SQlab ERGOWAVE®-series have common round struts with a diameter of 7 mm made of a metallic alloy. These can be
mounted on most commercially available seat posts with few restrictions. The saddles of the SQlab ERGOWAVE® series with the addition
"Carbon" have oval struts made of carbon fibre with 7 mm width and 9.6 mm height. Separate regulations apply here which are listed
below. The model SQlab 6OX Trial Fabio Wibmer has no seat stays, it is designed for the use of a Tripod seat post and can only be used
with such a seat post. The 6OX Trial Fabio Wibmer is therefore NOT compatible with standard seatposts.
The functional principle, the clamping forces and the quality of workmanship, especially
the contact surfaces and edges of the seat post can affect the durability of the saddle or
its saddle frame and possibly cause damage.
Never mount your SQlab ERGOWAVE® saddle on unsuitable seat posts, but only on seat
posts that meet the following criteria:
The clamping of the struts must have a length "A" (or seat post
distance) of at least 32 mm. The minimum length "B" and "C"
of each individual clamping surface must be at least 7 mm.
OK

Length "A" of the upper clamping jaw must be at least 32 mm
and positioned within the (possibly) longer lower jaw "B".
OK

Even with seat posts with a clamping mechanism that is trans-
verse to the direction of travel, the clamping length "A" must
be at least 32 mm
OK

Warning
Always follow the instructions and
warnings given in the assembly and
operating instructions that accompa-
ny your seat post.
