Assembly compatibility and operational safety

The SQlab 600 active has common round saddle rails with a diameter of 7 mm made of a metallic alloy. These can be mounted on most
common seat posts with few restrictions. Due to its unusual shape, seat posts are more heavily loaded by the SQlab 600 active than by
conventional saddles. The use of seatposts with two clamping bolts is strongly recommended by us. If you have any questions regarding
the compatibility of your seat post, please contact the manufacturer.
The functional principle, the clamping forces and the quality of workmanship, especially
the contact surfaces and edges of the seat post can affect the durability of the saddle or
its saddle frame and possibly cause damage.
Therefore never mount your SQlab 600 active saddle on unsuitable seat posts, but only on
seat posts that meet the criteria below:
The clamping of the struts must have a length "A" (or seat post
distance) of at least 32 mm. The minimum length "B" and "C" of
each individual clamping surface must be at least 7 mm.
OK

Length "A" of the upper clamping jaw must be at least 32 mm
and positioned within the perhaps longer lower jaw "B".
OK

Even for seat posts with a clamping mechanism that is transver-
se to the direction of travel, the clamping length "A" must be at
least 32 mm.
OK

Warning
Always follow the instructions and
warnings given in the assembly and
operating instructions for your sadd-
le.
