POINT B - SETTINGS
DIP 1 (ON) MOTORS ROTATION DIRECTION CHECK (See Point C)
DIP 2 (ON) - setting the times (point D)
DIP 2-1 setting the pedestrian opening times (point E)
DIP 1-2 save/delete radio control codes for total opening (point F)
DIP 1-3 save/delete radio codes for pedestrian opening (point G)
DIP 1-2-3 save/delete radio codes for relay r-aux command (point H)
DIP SWITCHES CONTROL
DIP 4 Photocells always active (OFF) - Photocells active only during closing (ON)
DIP 5 Pre-blinking (ON) - Normal blinking (OFF)
DIP 6 Single pulse command (START) and RADIO - step-by-step (ON) - automatic (OFF)
DIP 7 Photocells AUTO-TEST activation (ON-activated).
DIP 8 Electric lock activation (ON-activated)
DIP 9 Electric lock pulse release (ON-activated)
DIP 10 Motors manual release facilitation (ON-activated)
DIP 11 Electric lock pulse engagement (ON-activated)
DIP 12 Selection of 1 or 2 motor operation (by factory OFF 2 motors)
DIP 13 Activate the radio system SUN (ON) - SUN-PRO (OFF)
DIP 14 Timed operation (OFF) - Operation with limit switches (ON)
DIP 15 Slowdown (ON - activated)
DIP 16 Contactors management (ON - activated)
DIP 17 Encoder management (ON - activated)
TYPE OF MOTOR
R50
TORQUE TRIMMER - Electronic regulator for motor torque
Adjustment of motor torque is carried out using the TORQUE Trimmer which varies the output
voltage to the head/s of the motor/s (turn clockwise to increase torque).
This torque control is activated after 2 s form any manoeuvre begging, whereas the motor is
turned on at full power to guarantee the starting at the manoeuvre begging.
PAY ATTENTION: IF THE TORQUE TRIMMER SETTING IS CHANGED, IT IS PREFERABLE TO REPEAT THE
TIME PROGRAMMING.
LOW SPEED TRIMMER - Electronic regulator for low speed on approach
Adjustment of low speed is carried out using the LOW SPEED Trimmer which varies the output
voltage to the head/s of the motor/s (turn clockwise to increase speed). Adjustment is carried
out to establish the correct speed at the completion of opening and closing, depending on the
structure of the gate, or if there is any light friction that could compromise the correct working
of the system. The low speed is activated (DIP 15 ON) when the gate leaf is 0.50-0.60 meters
away from the complete close or open position.
TCA TRIMMER - AUTOMATIC CLOSING pause time regulator for TOTAL or PEDESTRIAN openings
- by factory NOT ACTIVATED and LED DL11 OFF
(trimmer fully rotated counterclockwise)
This trimmer makes it possible to adjust the pause time for total or pedestrian automatic
closing. Only with gate completely open (total) or partially open (pedestrian) and LED DL11 to
ON (trimmer rotated clockwise to activate the feauture).
The pause time (for a totally opened gate) can be adjusted from a minimum of 2 s up to a
maximum of 2 minutes.
The pause time (for gate open with PED. control) can be adjusted from a minimum of 2 s to a
maximum of 30 seconds.
Ex: With TCA trimmer setted halfway, you will have 1 minute pause after the total opening and 15
s of pause after the pedestrian opening prior to have the auto-close of the gate.
R-AUX - AUXILIARY RELAY CONTACT (NO)
By by factory this relay is set as courtesy light (max 700 W - 3 A - 230 Vac) to operate 3 minutes
at each command, with time renewed at each command.
You can activate the R-AUX contact by TRANSMITTER by performing the memorization
procedure described in point H.
LED WARNING
DL1 PROG programming activated
DL2 M1 - gate opening
DL3 M1 - gate closing
DL4 M2 - gate opening
DL5 M2 - gate closing
DL6 STOP command (NC)
DL7 PHOTO 1 contact (NC)
DL8 PHOTO 2 contact (NC)
DL9 EDGE 1 contact (NC)
CODE DIP 18 DIP 19
AA21580 OFF ON
(red)
(green)
(red)
(green)
(red)
(red)
(red)
(red)
(red)
DL10 EDGE 2 contact (NC)
DL11 TCA - automatic closure time enabled
DL12 Remotes programming enabled
DL13 Card managed by APP
DL14 Opening limit switch LSO M1/ENC
DL15 Closing limit switch LSC M1
DL16 Opening limit switch LSO M2/ENC
DL17 Closing limit switch LSC M2
DL18 PROG and RADIO (on MOLEX connector) commands
B.I.O Clock command (NO)
PED. Pedestrian command (NO)
START Single impulse command (NO)
CLOSE CLOSE command (NO)
OPEN OPEN command (NO)
C - MOTOR/S ROTATIONAL DIRECTION CONTROL
1 - Unlock the operators with the Manual Release - swing open the leaves about halfway and
lock again the operators.
2 - Turn DIP 1 to ON position The red LED DL1 starts blinking.
3 - Press the PROG button and hold it - When GREEN LEDS DL2 and DL4 are on, the gate leaves are
opening (with a phase shift of 2 s). Check the leaves swinging and the opening mechanical
stopper position (movement is now performed in "man present" mode, open-close-open-
etc.).
DIP 20
If any of the leaf closes instead of opening, release PROG button, turn OFF the main power
ON
and reverse the two phase wires (V1/2 and W1/2) of the relevant motor/s.
4 - Press the PROG button and hold it to CLOSE completely the gate. When RED LEDS DL5 and DL3
are on, the gate leaves are closing (with a phase shift of 2 s). Check leaves swinging and the
closing mechanical stopper position.
5 - After 2 s motor starting and for the next 10 s motor working, the torque controls
automatically activated. Set the motor torque by the TORQUE Trimmer/s which varies the
output voltage to the motor/s (turn clockwise to increase the torque).
6 - After other 10 s motor working, the low speed controls automatically activated (DIP 15 ON).
Set the motor low speed by the LOW SPEED Trimmer to select the gate leaf low speed in
approaching.
7 - Close completely the gate.
8 - Turn DIP 1 to OFF position, LED DL1 turns OFF.
During Point C procedure, safety devices (photocells and safetystrip) are not active.
D - TIMES PROGRAMMING
N.B.: DURING PROGRAMMING THE SAFETY DEVICES ARE ACTIVE AND THEIR
INTERVENTION STOPS PROGRAMMING (THE DL1 LED FROM FLASHING REMAINS
ON FIXED) AND THE BUZZER PLAYS FOR 10 s. TO REPEAT THE PROGRAMMING
PROCEDURE POSITION THE DIP 1 AND DIP 2 TO OFF, CLOSE THE GATE THROUGH
PROCEDURE «CHECKING THE DIRECTION OF MOTOR ROTATION» AND REPEAT THE
PROGRAMMING OF THE CHOICE.
N.B.: The deceleration is automatically determined during the times programming,
and is activated about 50÷60 cm before the end of opening or end of closing.
- FOR 2 MOTORS WITH ELECTRIC LIMIT SWITCHES - DIP 12 OFF AND DIP 14 ON
1 - The gate must be completely closed.
2 - Set DIP 2 to ON => LED DL1 will flash briefly.
3 - Press the PROG./RADIO/OPEN/START button => M1 opens.
When the opening limit switch LSO M1 is pressed, M1 stops and M2 opens.
When the opening limit switch LSO M2 is pressed. M2 stops.
4 - Press the PROG./RADIO/OPEN/START button => M2 closes.
5 - Press the PROG./RADIO/OPEN/START button => M1 closes and determine the phase
displacement between M2 and M1.
When the LSC M2 and LSC M1 limit switches are pressed, the motors are switched OFF.
At the same time the programming LED DL1 stops flashing, signaling the output from the
learning procedure.
From this moment the safety devices or other gate commands will work normally (inversions,
stops, alarms, etc.).
6 - AT THE END OF PROGRAMMING,
- FOR 1 MOTOR WITH ELECTRIC LIMIT SWITCHES - DIP 12 ON and DIP 14 ON
1 - The gate must be completely closed.
2 - Set DIP 2 to ON => LED DL1 will flash briefly.
3 - Press the PROG./RADIO/OPEN/START => M1 button. The M1 LSO opening limit switch will
stop M1.
4 - Press the PROG./RADIO/OPEN/START => M1 button to close. The LSC M1 limit switch will
34
(red)
(red)
(red/green)
(blue)
(red)
(red)
(red)
(red)
(green)
(green)
(green)
(green)
(green)
(green)
RESET THE DIP 2 IN OFF POSITION.
