6 Putting into operation
EN - 12
NOTE
• Only if the cable assembly connection (4) has been correctly inserted
can it be fastened properly with the fastening screw (11).
1 Open the lock ring (2).
2 Unscrew the fastening screw (11) from the welding torch interface (9) until
the screw head and washer (10) make contact.
3 Introduce the cable assembly (5) from behind through the robot (3).
4 Insert the cable setting tool (1) from the front through the iSTM and the
robot (3) and screw it into the cable assembly connection (4) as far as it
will go.
5 Position the cable assembly connection (4) by means of the
positioning pin (8) and the groove of the welding torch interface (9).
6 Pull in the cable assembly connection (4) as far as it will go and secure it
with a fastening screw (11). Max. tightening torque M= 7.5 Nm. Observe
the forced positioning.
7 Unscrew the cable setting tool (1).
NOTE
Press the corrugated hose of the cable assembly (5) into the webs of the
clamp (6) and turn the corrugated hose by hand until it rotates in the
clamp (6).
8 Insert the corrugated hose of the cable assembly (5) into the clamp (6) and
clamp it using the cylinder screws (7).
