4.3 Wiring diagrams

The following picture shows the product wiring diagram.
AUTO LINE-UP AUTO LINE-UP AUTO LINE-UP AUTO LINE-UP AUTO LINE-UP
YELLOW - AWG 18
PURPLE - AWG 18
SECOND STATION SECOND STATION SECOND STATION SECOND STATION SECOND STATION
CONNECTIONS CONNECTIONS
CONNECTIONS CONNECTIONS CONNECTIONS
EASY- JOY EASY- JOY EASY- JOY EASY- JOY EASY- JOY
FIRST FIRST FIRST STATION STATION STATION
FIRST FIRST STATION STATION
1 (see par. 4.3.1)
RED - AWG 14
BLACK - AWG 14
BLACK
BLACK/RED - AWG 16
WHITE/RED - AWG 16 WHITE
BLACK/GREEN - AWG 16
BLACK
WHITE/GREEN - AWG 16
WHITE
ORANGE- AWG 18
2 (see par. 4.3.2)
BLACK/ORANGE - AWG 18
WHITE/ORANGE - AWG 18
BLU E- AWG 18
GREY - AWG 18
GREEN - AWG 18
3 (see par. 4.3.3)
Installation and maintenance manual
15A MAGNETO-THERMAL SWITCH
WHICH CAN BE MANUALLY RESET
(NOT SUPPLIED)
+12V (POWER POSITIVE WIRE)
GROUND BAR
SECOND SECOND SECOND SECOND SECOND STATION STATION STATION STATION STATION
( O P T I O N A L ) ( O P T I O N A L ) ( O P T I O N A L ) ( O P T I O N A L ) ( O P T I O N A L )
BLUE - AWG 18
YELLOW - AWG 18
GREY - AWG 18
PURPLE - AWG 18
GREEN - AWG 18
ELECTROMECHANICAL TRIM TABS
STARBOARD ACTUATOR
è
PORT ACTUATOR
