ner (in tool kit (# 9654)).
Mount paint needle seal
■ Screw paint needle seal [# 6445] into gun body using socket spanner
(in tool kit (# 9654)).
■ Mount trigger guard [1-12] (see chapter 9.1).
■ Insert spring and paint needle.
■ Screw adjusting screw [1-4] with counter nut into gun body.
After installation, adjust the material flow according to chapter 8.2.
9.4. Replace air piston, air piston spring and air micrometer
Risk of injuries from air micrometer coming loose.
When the locking screw is not screwed tight, the air micrometer can
shoot uncontrolled out of the spray gun.
→ Check that the locking screw of the air micrometer fits firmly and
tighten if necessary.
Replacement is necessary if
air escapes at the air cap or air micrometer without actuating the trigger
guard.
Dismantle air piston, air piston spring and air micrometer
■ Screw locking screw [1-6] out of gun body.
■ Pull air micrometer [1-5] out of gun body.
■ Remove air piston with air piston spring.
■ Remove air piston rod [# 29629].
Mount air piston, air piston spring and air micrometer
■ Insert air piston rod [# 29629] in correct position.
■ Grease air piston with air piston spring and air micrometer [1-5] with
SATA high performance grease (# 48173) and insert.
■ Press air micrometer into gun body.
■ Screw locking screw [1-6] into gun body.
After installation, adjust the material flow according to chapter 8.2.
9.5. Repaling the sealing (air side)
Replacement is necessary if air escapes under the trigger guard.
Remove seal
■ Loosen counter nut.
■ Screw adjusting screw [1-4] with counter nut out of gun body.
■ Remove spring and paint needle.
Warning!
