Item Part No.
10 64025-19
11 3006300
12 2000787
13 3002502
14 441625
15 391040
16 391039
17 64006-05
18 400410
19 64123-16
20 64123-50
21 1001885.6
22 64123-89
23 64140-14
24 367461.7
25 552824
26 163425
27 3002737
28 1003733
29 64006-01
30 64025-01
31 471214
32 2720198
33 2720171.6
34 365772
35 366548
36 365772
37 3004894
38 460050
39 3000487
40 346913
41 503573
42 453013
43 366562
44 400348
45 367140
46 64123-32
47 64163-19
48
> Denotes change from previous revision
Figure-25 Front Deck
Qty. Description
4 Nut-hex 1/2-13
1 Pin,clevis
1 Decal-No Step
3 Decal, Danger
18 Bolt 3/8 X 1-1/2 Carriage
1 Blade
2 Blade,rotary L.H.
7 Lockwshr-helical 1/2
3 Screw 1/2-13 X 1-3/4 Hex
6 Blt-hex 3/8-16x1-1/4
2 Blt-hex 3/8-16x1
3 Adapter, Blade Assem
1 Blt-hex 1/4-20x3/4
1 Cotter Pin-1/4x3-1/2
1 Plate-baffle Deck
2 Bushing
1 Roller
1 Shaft-roller
1 Caster Assem
1 Lockwshr-helical 1/4
1 Nut-hex 1/4-20
2 Fitting, Str. Stew. Warner
2 Bushing-caster
2 Wldmt-caster Arm
8 Spacer, 1/2" Caster
2 Washer,spring Wave
2 Spacer
2 Pin-klik Type
2 Cotter Pin
1 Pin, Clevis
1 Spacer
1 Front Deck Assembly
2 Flatwasher 7/16
2 Wheel,deck
2 Bolt 7/16-14 X 3 Hex
2 Spacer,wheel
4 Blt-hex 1/2-13x3-1/2
8 33/64x1-1/4x12ga Washr
TEXTRON TURF CARE AND SPECIALTY PRODUCTS
Serial Numbers/Notes
Includes Item 25
See Figure-33
Includes Item 32
Includes Items 13,7 and 12
79
