Textron JACOBSEN HR 5111 Mode D'emploi page 173

Item Part No.
6 365974
7 131905
8 365967
9 163917
10 326112
11 365962
12 64001-11
13 446118
14 64025-14
15 64123-69
16 1002397
17 64006-01
18 64025-01
19 64163-46
20 64025-02
21 453023
22 345671
23 473137
24 340089
25 132535
26 345666
27 64123-07
28 64163-55
29 132446
30 340269
31 158007-07
32 132417
33 132484
34 365566
35 158061-02
36 J123015
37 2811255
38 556417
39 556419
40
64123-15
41 64006-03
42 3007980
43 3008126.7
44 473108
45 64123-68
46 366430
47 158059-03
48 158007-02
49 163574
50 365976
51 64123-60
52 2720726
> Denotes change from previous revision
Figure-11 Filter, Pump and Solenoid
Qty. Description
1 Switch
1 Solenoid
1 Hose
1 Fitting
2 Clamp
1 Wire
2 Nut-jam 5/16-24
2 Lockwasher-#10
2 Nut-hex #10-32
2 Blt-hex 5/16-18x1
1 Battery Cable Assy Positive
6 Lockwshr-helical 1/4
6 Nut-hex 1/4-20
2 Wshr.383/.393x.88x7ga
4 Nut-hex 5/16-18
4 Flatwasher, 1/4
2 Clamp, Hose ID 0.75
1 Tie,uv Blk Cable,3x7-9 Sunlite
1 Elbow, 90 Def Straight Thread
1 Tube Assem
1 Clamp, Hose ID 0.50
1 Blt-hex 1/4-20x1-1/2
4 Wshr .328x.75x14 Ga
1 Hose Assem
2 Tee, Straight Thread Run
2 Fitting-90 ORS/ORB
2 Hose Assem
1 Hose Assem
3 Clamp
1 S O-ring -08
1 Filter
1 Cartridge
1 Head, Filter
1 Switch, In-oil Single Post
4 Blt-hex 3/8-16x3/4
4 Lockwshr-helical 3/8
1 Bar, Spacer
1 Bracket, Tank
1 Terminal, Whitaker 2863 Insul
2 Blt-hex 5/16-18x1
2 Reducer
3 Fitting 45 ORS/ORB Adj
1 Fitting-90 ORS/ORB
1 Fuel Pump
2 Elbow
1 Blt-hex 1/4-20x2
1 Cable, Battery/Ground
TEXTRON TURF CARE AND SPECIALTY PRODUCTS
Serial Numbers/Notes
Includes Items 37 thru 39
53
