MASTER Wi-Fi POWER
After having made all of the connections, provide power to the control panel with
MASTER Wi-Fi.
The yellow LED DL6 should come on and the buzzer will emit a sound indicating
correct power.
The LED DL7 will alternately flash red and green indicating that no remote controls
or blinkers have been memorized.
F -
IDENTIFICATION OF Wi-Fi SAFETY DEVICES
Every Wi-Fi safety device must OBLIGATORILY be identified placing only one
of the 6 micro-switches present on its circuit (different for each of the 6 safety
devices) in the ON position. Obviously one pair of photocells is considered one
safety device and must therefore have a receiver and transmitter with the same
DIP in the ON position.
IDENTIFY THE CONTAINERS OF THE SAFETY DEVICES WITH THE NUMBER
OF THE ACTIVATED MICRO-SWITCH AND ATTACH THE NUMBERED
ADHESIVE STRIP SUPPLIED TO THE OUTSIDE OF EACH CONTAINER.
The adhesive strip serves as a means of quickly identifying the safety device when
it needs maintenance.
Note: Each safety device is supplied with the micro-switches in the OFF position
so that battery power is not consumed when not in use (if inserted).
Insert the batteries in the Wi-Fi safety devices.
G -
MEMORIZATION OF THE SAFETY DEVICES
After having performed the identification of the safety devices, and provided power
with the batteries, place the micro-switches with the same number of the safety
devices on the MASTER Wi-Fi in the ON position to activate the safety devices
to be memorized.
Use the following procedure for memorization:
- Push the button PROG RX on the MASTER Wi-Fi => dual-color LED EDGE
PHOT 1 flashes red for 1 minute (the time needed for memorization).
- Push the button PROG TX on the safety device with micro-switch 1 in the ON
position => on the MASTER Wi-Fi the dual-color LED EDGE PHOT 1 flashing
red turns green and a sound from the buzzer indicates that the safety device
has been memorized correctly, immediately the dual-color LED EDGE PHOT 2
begins flashing red.
- If there are no other safety devices to be memorized after one minute the dual-
color LED EDGE PHOT 2will turn off or, push the button PROG. RX 4 times
to end the memorization procedure => all of the dual-color LED EDGE PHOT
should be off.
SELF-TEST-ENABLED RIB ELECTRONIC BOARD CHART
RIB ELECTRONIC BOARD
BOSS 24V - BOSS 24V CRX
BOSS 230V - BOSS 230V CRX
T2 - T2 CRX
T2 24V - T2 24V CRX
PT2 - PT2 CRX
PARK - PARK CRX
K 2007 - K 2007 CRX
K 2007 with 24V power feed accessory
K 2007 CRX with 24V power feed accessory
K2 24V - K2 24V CRX
PK2 24V - PK2 24V CRX
S1 - S1 CRX
J - J CRX
KS (with EXPANDER PLEX)
KS2 (with EXPANDER PLEX)
KS 24V (with EXPANDER PLEX)
KS 24V CRX (with EXPANDER PLEX)
CONNECT A/D+ TEST TERMINAL
TO TERMINAL
Terminal 8
Terminal 8
D+ TEST
A+ TEST
D+ TEST
D+ TEST
D+ TEST
A+ TEST
A+ TEST
A+ TEST
A+ TEST
D+ TEST
Terminal 2 EXPANDER PLEX card
Terminal 2 EXPANDER PLEX card
Terminal 2 EXPANDER PLEX card
22
22
MEMORIZATION OF OTHER SAFETY DEVICES
- After having memorized the first safety device, the dual-color LED EDGE
PHOT 2 automatically begins flashing red for 1 minute (the time needed for
memorization).
- Push the button PROG. TX on the safety device with micro-switch 2 in the ON
position => on the MASTER Wi-Fi the dual-color LED EDGE PHOT 2 flashing
red turns green and a sound from the buzzer indicates that the safety device has
been memorized correctly.
- Follow the same procedure for any other safety devices (up to a maximum of 6).
NOVA Wi-Fi PHOTOCELLS SYSTEM CHECK
- Check that the micro-switch selected on the transmitter TX NOVA Wi-Fi is the
same as that selected on the receiver RX NOVA Wi-Fi (example 1 ON).
- Proper function of the TX NOVA Wi-Fi is shown by the green LED which comes
on for 10 seconds.
- Push and release the button S3 "PROG. TX" on the NOVA Wi-Fi receiver (it
activates for 3 minutes to perform the alignment procedure). If the photocells are
already aligned the red LED emits a constant light. If the red LED is off or emits
a flashing light, perform the alignment until it emits a constant light.
- After the alignment check by placing an obstacle that the red LED turns off and
that at the same time the dual-color LED EDGE PHOT associated with it during
memorization shines green on the MASTER Wi-FI for the time that the obstacle
is present.
- On the MASTER Wi-Fi card, LED DL3 should also be off indicating a proper
exchange of the dedicated input with the PHOT on the control panel.
- Repeat the procedure on the other installed NOVA Wi-Fi photocells.
- Perform a function check of all the installed photocells, activating the movement
of the automation and checking that by placing an obstacle the automation stops/
reverses when closing, or stops/continues to open when opening.
TOUCH Wi-Fi STRIP SYSTEM CHECK
After having calibrated the TOUCH Wi-Fi strip correctly:
- Push the contact of a TOUCH Wi-Fi strip (for example: safety device number 3).
- On the MASTER Wi-Fi check that the corresponding LED EDGE PHOT 3 flashes
green and that the paired LED DL2 momentarily turns off and then turns on.
ATTENTION: after receiving the first signal, other signals are ignored for 2
seconds. If there is a signal in these 2 seconds it will be from the LED EDGE
PHOT 3 which turns green.
- Repeat the LED activation check on the MASTER Wi-Fi pushing the other
TOUCH Wi-Fi strips installed.
- Perform a final check of all of the strips installed, activating the movement of the
automation and ensuring that upon impact with the strip the automation stops/
reverses movement.
ANTENNA
In order to communicate with 868 MHz Wi-Fi safety devices, MASTER Wi-Fi is
ENABLE SELF-TEST FUNCTION
THROUGH
DIP 6
DIP 6
DIP 13
DIP 12
DIP 13
DIP 9
DIP 10
DIP 10
JUMPER JP4
JUMPER JP4
DIP 12
DIP 7
Activated by inserting EXPANDER PLEX
Activated by inserting EXPANDER PLEX
Activated by inserting EXPANDER PLEX
PLACE JUMPER JP1 ON
THE MASTER WI-FI CARD IN
POSITION:
+/~
JP1
_
JP1
