REMOTE CONTROL

This controls all the functions.
Key to buttons and display:
: to turn off and on (to go from remote control on stand-by to remote control on)
+/- : to increase/decrease the various regulations
A : to select Automatic function
M : to select Manual function and access the control and programming menus
The display also shows other useful information in addition to the icons described above.
- Stand-by position:
shows room temperature (20°C), kg of pellets (15 kg) remaining in tank and current time (15.33)
- Manual work phase:
shows power set (Power 1), room temperature (20°C), kg of pellets and autonomy remaining (15 kg 21 hrs)
- Automatic work phase:
shows temperature set (Set 22°C), room temperature (20°C), kg of pellets and autonomy remaining (15 kg 21 hrs).
DO NOT PRESS THE BUTTON MORE THAN ONCE
Note: If the radio control is not used for a few seconds, the display will go dark as it has moved into the power saving function.
The display can be reactivated by pressing any button.
INSTRUCTIONS FOR USE
- 51
- icon " ashing: remote control searching for network
- icon ! xed: remote control with connection enabled
keypad locked (press "A" and "M" in parallel for a few seconds
to lock or unlock the keypad)
" at battery (3 mini alkaline batteries type AAA)
programming enabled
alphanumeric display consisting of 16 ! gures arranged in two
lines of 8 ! gures
- icon " ashing: Insert turning on
- icon ! xed: Insert working
manual adjustment function (display shows working power)
automatic function (display shows temperature)
.
-
