Specifi cations
MODEL WEIGHT HEIGHT
D55672 160 lbs. 25.15"
(72.57 kg) (638.8 mm)
Hot Surfaces
FIG. 2
COMPRESSOR
CYLINDER & HEAD
ENGINE
MUFFLER
GASOLINE
ENGINE
WIDTH LENGTH CAPACITY
(GALLONS)
18.25" 43"
(463.55 mm) (1092.2 mm) (30.2 liters)
OUTLET TUBE
PUMP
CRANKCASE
IF YOU HAVE ANY QUESTIONS OR COMMENTS ABOUT
THIS OR ANY D
1-800-4-D
3
AIR TANK APPROX.
BLOW OFF
PRESSURE
8 150 PSI
Defi nitions: Safety Guidelines
The definitions below describe the level of severity
for each signal word. Please read the manual and
pay attention to these symbols.
DANGER: Indicates an imminently hazardous
situation which, if not avoided, will result in death
or serious injury.
WARNING: Indicates a potentially hazardous
situation which, if not avoided, could result in death
or serious injury.
CAUTION: Indicates a potentially hazardous
situation which, if not avoided, may result in minor
or moderate injury.
CAUTION: Used without the safety alert symbol
indicates a potentially hazardous situation which, if
not avoided, may result in property damage.
WALT TOOL, CALL US TOLL FREE AT:
E
WALT (1-800-433-9258)
E
TYPICAL VALUES
@ 100 PSI SCFM
9.0
Tested per ISO 1217
