HYGRASGARD
ASCII Code Table for Dot Matrix Display Area
ASCII Sign
32 Blank
33 !
34 "
#
35
36 $
37 %
38 &
40 (
)
41
42 *
43 +
44 ,
45 -
.
46
47 /
48 0
49 1
50 2
3
51
52 4
ASCII characters or control characters are displayed as spaces.
LED DISPLAY
Individual LED display (Register 4x0014 = 0)
The colour and brightness of LEDs can be controlled individually via Modbus.
With the registers 4x0015 to 4x0019 (LED x mode, x=1...5), the correspondingdisplay status of the LED can be set (continuous
light, various flashing options) or the LED presence buttons can be assigned.
Registers 4x0020 to 4x0024 (LED x colour, x=1...5) can be used to set thecolour and brightness of the LED (see table). The tens
stand for the colour while the units stand for brightness. For colour and brightness allocation, the value 100 refers to the corre-
sponding LED colour register (4x0025 to 4x0039) with the option of individually assigning the three colours red, green and blue.
The LED displays are switched on and off individually through the MODBUS telegram "Function 05 Write Single Coil".
The adjacent register settings correspond to the follow-
ing example of various operating fault messages:
LED 1 red Alarm – flashes quickly
LED 2 yellow Warning – flashes slowly
LED 3 white operation
LED 4 green operation
LED 5 white Presence including connection with
button
RFTF - Modbus | Configuration, Telegrams
ASCII Sign
53 5
54 6
55 7
8
56
57 9
58 :
59 ;
60 <
=
61
62 >
63 ?
64 @
65 A
B
66
67 C
68 D
69 E
70 F
G
71
72 H
ASCII Sign ASCII
73 I
74 J
75 K
L
76
77 M
78 N
79 O
80 P
Q
81
82 R
83 S
84 T
85 U
V
86
87 W
88 X
89 Y
90 Z
[
91
93 ]
= 0 (LEDs individually addressable)
4x0014
4x0015 = 4 (quick flashing)
= 2 (medium flashing)
4x0016
= 0 (continuous light)
4x0017
4x0018 = 0 (continuous light)
= 5 (status change via presence button)
4x0019
4x0020 = 35 colour red
= 25 colour yellow
4x0021
= 5 colour white
4x0022
4x0023 = 55 colour green
= 5 colour white
4x0024
18
Sign ASCII
94 ^ 114
95 _ 115
96 \ 116
a
97 117
98 b 118
99 c 119
100 d 120
101 e 121
f
102 122
103 g 123
104 h 124
105 i 125
106 j 129
k
107 132
108 l 142
109 m 148
110 n 153
111 o 154
p
112 223
113 q
Sign
r
s
t
u
v
w
x
y
z
{
|
}
ü
ä
Ä
ö
Ö
Ü
°
