Sigfox Smart Building MOTION - Guide utilisateur / User guide version V1.0.1

3.3. Description of the registers

On start up the device operates according to the last saved configuration (Factory Configuration if it is the first start up, or if this configuration
has not been changed).
The IoT Configurator or a change command of the type ATS <n> = <m> allows you to change the content of the registers: <n> representing
the register number and <m> the value to be assigned. The latter is either a decimal value or a hexadecimal value consistent with the «Encod-
ing» column of the tables below.
As examples:
FR
• ATS300 = 6 assigns the decimal value 6 to the 300 register
• ATS302 = 2 assigns hexadecimal value 0x02 to register 302
It is imperative to save the parameters by the command AT&W before exiting the Command mode otherwise all changes will be lost.
IMPORTANT: Undocumented registers (which may appear in the list following the AT/S command) in the following paragraphs are reserved and
must not be changed.

3.3.1 Function registers

EN
The list of registers below allows you to change the behavior of the device application
3.3.1.01 General registers
Register Size (bytes)
S300 2
S301 2
S303 1
S304 1
S306 2
S308 4
S320 2
S321 2
* The PIN code protects the device configuration. After 3 incorrect attempts the device is blocked. To unblock it, call the support service
Note concerning the register S301
3.3.1.02 Caution: in order to give more freedom to the user the device has not been limited to a maximum number of backups per
frame depending on the network used. We therefore strongly recommend not exceeding the maximum number of readings authorized by the
network if you do not want to lose data (the oldest readings will be overwritten in favor of the most recent ones). If this occurs, an indication
is given in the data-frame byte status (explained in section 4.1.8).
Description
Transmission period of the Keep
Alive frame
Number of backups (history logs)
to be done before sending a
frame (thus defining the sending
period)
Acknowledgment of the uplink
frames
PIN* code
Operating mode
LED activity
Number of readings to be
performed before saving in the
history logs
Period of acquisition (reading)
DISTRIBUTED BY TEXIM EUROPE
Encoding Details
Decimal Default: 8640
Min/max: 2 to 65535 Unit: x 10 seconds
The value of 8640 equals a period of 24 hours.
Decimal Default: 1
Min/max: 0 to 65535
The value 1 equals 1 frame sent for each backup. The value 0 is
equivalent to disabling the periodic mode.
See note below
Decimal Default: 0 (disabled)
Min/max: 0 to 1
The value 1 activates the acknowledgment request
Decimal Default: 0 (disabled)
Min/max: 0 to 9999
PIN code used with the ATPIN command.
A value of 0 disables the PIN.
Decimal Default: 0
Switches the device to one of the following modes:
• 0: PARK mode
• 1: PRODUCTION mode
• 2: Reserved (do not use)
• 3: REPLI mode
Hexadeci- Default: 0x4007F Other possibility:
mal 0x00000070: disable LEDs except low battery activity, REPLI
mode and faulty device
Decimal Default: 1
Min/max: 1 to 65535
The value 1 is equivalent to 1 backup per reading
Decimal Default: 1800
Min/max: 0 to 65535
Unit: x2 seconds
The value 1800 equals 1 hour (1800x2 / 60/60)
