Connection terminals

Range
Electrical connection
Connection possibilities
Starting torque
Stripping length
EDK82ZAFCC−100 DE/EN/FR 6.0
Values
Plug connector with screw connection
rigid:
1.5 mm
flexible:
without wire end ferrule
1.5 mm
with wire end ferrule, without plastic sleeve
1.5 mm
with wire end ferrule, with plastic sleeve
0.5 mm
0.22 ... 0.25 Nm (1.9 ... 2.2 lb−in)
7 mm
l
Electrical installation
Connection terminals
2
(AWG 16)
2
(AWG 16)
2
(AWG 16)
2
(AWG 20)
6
49
