3.3.1.04 Registers that configure digital input alarm(s)
Register Size Description
(bytes)
S380 1 Configuration
of the digital
input / ouput
1
S381 2 Digital input/
output 1
threshold
S382 1 Configuration
of the digital
input / ouput
2
Encoding Details
Hexadecimal Default: 0x41
Min/max: <7:4> Debounce time
0: No debounce time
1: 10 ms
2: 20 ms
3: 50 ms
4: 100 ms
5: 200 ms
6: 500 ms
7: 1 s
8: 2 s
9: 5 s
A: 10 s
B: 20 s
C: 40 s
D: 60 s
E: 5 minutes
F: 10 minutes
< 3:0> Type
0 = OFF
1 = Event ON (rising front)
2 = Event OFF (declining front)
3 = Event ON/OFF (rising and declining front)
4 = Output (default state = 0/OPEN)
5 = Output (default state = 1/CLOSE)
Decimal Default: 1
Min/max: 1 to 65535
The value 1 equals 1 detection
When the number of event is egal or higer than this threshold an alarm is triggered.
Hexadecimal Default: 0x0
Min/max: <7:4> Debounce time 0: No debounce time
1: 10 ms
2: 20 ms
3: 50 ms
4: 100 ms
5: 200 ms
6: 500 ms
7: 1 s
8: 2 s
9: 5 s
A: 10 s
B: 20 s
C: 40 s
D: 60 s
E: 5 minutes
F: 10 minutes
0 = OFF
1 = Event ON (rising front)
2 = Event OFF (declining front)
3 = Event ON/OFF (rising and declining front)
4 = Output (default state = 0/OPEN)
5 = Output (default state = 1/CLOSE)
