1. Basic safety information

Before first use, please read the
operating instructions carefully.
These provide important safe-
ty information and informa-
tion concerning use and maintenance
of the tool.
A damaged tool could endanger your
safety! Decommission the tool immedia-
tely and contact your suppliers.
This tool complies with the prescribed
safety regulations. Repairs must be
undertaken only by trained personnel.
Improper repairs can represent a con-
siderable risk for the user. Warranty pro-
visions can be implemented only in the
event that original Wohlhaupter spare
and accessory parts are used.
Keep the Operating instructions for use
in a safe place for future use.

2. Operating

Clamping and releasing
To guarantee a proper function of the CNC
drill chucks please follow the below men-
tioned instructions:
Clamping or releasing only at
standstill of machine spindle or
outside the machine.
2
1
Fig. 1
8
The CNC drill chuck
means of an Allen-T-wrench
the drill chuck actuating a bevel gear. Turn
the Allen-T-wrench counter clockwise to
open the drill chuck, clockwise to close it –
shown at the bore of the bevel pinion.
("+" means to close or clamp)
("–" means to open)
2
1
Fig. 2
1st step
Open the jaw of the drill chuck wide
enough to insert the cutting tool
2nd step
2
Fit cutting tool to the stud into the CNC
1
drill chuck so that the tool shank is fit
closely to the whole length of the clamping
jaws (Fig. 1).
3rd step
Turn the Allen-T-wrench
clamp the cutting tool using the torque
mentioned in the table on page 11 to
clamp the tool properly (Fig. 2).
1
is clamped by
3
on side of
3
2
.
3
clockwise to
