DESCRIPTION
1. Upper guard
2. Lower guard
3. Cover plate
4. Cover plate screw
5. Sliding fence
6. Table
7. Base
8. Mitre indicator
9. Bevel lock lever
10. Top carry handle
11. Slide tube(s)
12. Slide lock knob
13. Slide fence lock knob
14. Combination wrench
15. Mitre lock lever
16. The repeat-A-Cut
17. Depth adjustment clamp slide lock knob
& Head hold down
18 Arbor lock pin
19. Lower guard safety lock knob
20. ON/OFF switch
21. Bevel index pin
22. Front carry handle
23. Workpiece clamp
24. Bevel indicator
25. Cord wrap brackets
26. Saw blade
27. Arbor screw (Left hand thread)
30. Blade flanges
31. Blade washer
32. Clamp support shaft
33. Quick release buttom
34. Mitre index wheel
35. Depth adjustment knob
36. Slide rail
37. Pivot assembly
38. Grub screw
39. Back fence
40. Bevel scale
41. Locking jam nuts
42. Hex lock nut
43. Mitre scale
44. Spacer
45. Roller
46. Torsion spring (inside)
47. Arm pivot shaft
48. Dust bag
49. Dust bag frame
50. Dust elbow
E I P NL S DK N FIN
English
STANDARD ACCESSORY
6.35 mm Hex "L" Combination wrench
Workpiece clamp
Dust Bag
Owner's manual
Dust bag frame
Dust elbow
UNPACKING
WARNING
To reduce the risk of injury from unexpected
starting or electrical shock, do not plug the power
cord into a power source outlet during unpacking
and assembly. This cord must remain unplugged
whenever you are working on the saw.
This Miter Saw is shipped complete in one box.
WARNING
Although compact, this saw is heavy. To reduce
the risk of back injury, get help whenever you
have to lift the saw.
Before removing the miter saw from the carton tighten
■
the slide lock knob to guard against sudden movement.
Remove the miter saw from the carton by lifting the
■
saw with the carrying handle.
Place the saw on a secure, stationary work surface
■
and look the saw over carefully.
WARNING
If any part is missing or damaged, do not plug
the saw in until the missing or damaged part is
correctly replaced. To avoid electric shock,
use only identical replacement parts when
servicing double insulated tools.
INSTALLING OR REMOVING THE BLADE
INSTALLING OR REMOVING THE BLADE
(FIG. 1 & 2)
WARNING
To reduce the risk of injury from a thrown
workpiece or thrown pieces of blade, do not use
a blade larger or smaller than 305 mm diameter.
WARNING
To reduce the risk of injury from unexpected
starting, unplug the saw whenever you are
removing or installing the blade.
