ASSEMBLY
 Reposition the riving knife left or right as needed to align
the riving knife with the saw blade.
 Once properly aligned, securely retighten all screws.
 Check again for squareness and continue to adjust if
needed.
TO CLOSE/OPEN THE LEG STAND
See Figures 23 - 29.
 Remove any workpieces from the tool.
 Remove and securely store any tools or accessories such
as rip fence, miter gauge, clamps, blade guard, etc.
 Lower the saw blade.
RELEASE
LEVER
Fig. 23
Fig. 24
To close the leg stand:
 At the same time, step on the release lever, grasp the
grips, and lift the grips up and away from the body.
 Push the table saw until the release lever clicks and locks
into place.
To move the leg stand:
 Holding the grips firmly, pull grips toward you until the
leg stand and saw are balanced on the wheels.
 Push the saw to the desired location then either open
the leg stand for saw operation or store the saw in a dry
environment.
22 − English
Fig. 25
Fig. 26
