POS. DESCRIPTION
1
SCREW
2
WINDLASS CASING "PT PLAST" SERIES
3
PLUG
4
NUT
5
WASHER
6
GEAR Z100 M1.5
7
GEAR Z20 M1.5
8
GEAR Z80 M1
9
GEAR Z16 M1
10
PT SPACER
11
INTERNAL CIRCLIP
12
BEARING
13
ESTERNAL CIRCLIP
14
INTERNAL CIRCLIP
15
BEARING
16
SCREW
17
SCREW
18
WINDLASS BASE PT SERIES
19
PLUG L
20
OIL SEAL
21
WINDLASS EXTRUDED PT SERIES
22
CABLE OUTLET PT
23
SHAFT PT 1 SERIES
24
SHAFT PT 2 SERIES
25
SHAFT PT 3 SERIES
26A
WINDLASS MOTOR 150W 12V PT
26B
WINDLASS MOTOR 250W 12V PT
26C
WINDLASS MOTOR 350W 24V PT
27
NUT
28
SCREW
29
WINDLASS REEL "PT PLAST" SERIES
30
WINDLASS BASE PT SERIES
31
MICROSWITCH BUTTON 16A/250W
32
REVERSING CONTACTOR CARD 45A
33
SCREW
34
GEAR Z100 M1
35
GEAR Z20 M1
36
COMPLETE BOW ROLLER PT STAINLESS STEEL
37
SCREW
38
SCREW
39
COVER BASE PT SERIES STAINLESS STEEL
PONTOON 350 - 700 - 1000 - REV002A
WARNING: make sure the electrical power to the motor is
switched off when working manually on the windlass. Care-
fully remove the rope from the reel.
Quick
windlasses are manufactured with materials resistant
®
to marine environments. In any case, any salt deposits on the
outside must be removed periodically to avoid corrosion and
damage to the equipment.
The parts where salt may have built up should be washed thor-
oughly with fresh water.
MAINTENANCE
EN
23
