• Never open or modify the unit or the cuff - this is a medical device and may
only be opened by authorised specialists. (Exception: replacing batteries). If
the unit has been opened, it must be subjected to a metrological inspection
by an authorised institution.
• The cuff may be inflated on the arm only.
• Please comply with the specified operating conditions for measurement. See
Technical data, Page EN-82.
• The inflating and measuring procedure can be Stoped by pressing the Start/
Stop button. In this case, the unit stops the inflation procedure and deflates
the cuff.
EN-52
Safety instructions Operating the unit

1. Unit description

11 13
12
6
10
9
Cuff
Start/Stop button for user 1
1
Memory recall button
2
Start/Stop button for user 2
3
Displays
4
Battery compartment (removable
5
battery compartment cover)
Cuff
6
Marking for arm circumference
7
Artery marking
8
C
14
15
1
2
3
5 4
8 7
Microphone
9
Microphone cable
10
Measurement arrow for arm cir-
11
cumference
Air hose and microphone cable
12
Cuff socket
13
USB connecting socket
14
Connecting socket for mains
15
adapter
