Only use the supplied charger (AQUATEC
ORCA / ORCA F / ORCA XL) to charge the
battery in the hand control.
Recharge the battery in the hand control as
soon as possible after use.
To preserve the service life of the battery
when not in use for prolonged periods,
please observe the instructions in
section 7.2.
Only plug the charger into the mains if the
hand control is connected to the charger.
Do not dispose of batteries in the household
waste.
3

Description

3.1

Scope of delivery

The AQUATEC ORCA / ORCA F / ORCA XL is
supplied with the following parts (fig. 1 to fig. 3):
Seat (fig. 1) consisting of:
1 Sideflap
2 Seat plate
3 Hinge for backrest
4 Lifting scissors
5 Spindle foot retainer
6 Rear suction cup (double strap with thread)
7 Base plate
8 Guide for gliding shoe
9 Gliding shoe
10 Front suction cup (single strap with head)
Backrest (fig. 2) consisting of:
1 Jack plug
2 Drive
3 Spindle foot
4 Lock pin
5 Backrest plate
Hand control and charger (fig. 3)
1 Hand control and curled cable
3 Charger
The battery is built into the hand control.
Operating instructions (not illustrated)
3.2

Technical data

Bathlift
Overall length in the lowest position:
Overall length in the highest position:
Overall height in the highest position:
12
Seat length:
Seat width with sideflaps folded out:
Seat width with sideflaps folded in:
Seat height at lowest position:
Seat height at highest position:
Width of the backrest:
Minimum angle of the backrest:
Width of the base plate:
Max. load (ORCA / ORCA F):
Max. load (ORCA XL):
Total weight without hand control:
Seat weight:
Backrest weight:
Hand control weight:
Charger weight:
Operating force for the hand control buttons:
Operating voltage:
Rated current:
Battery type:
Charger input:
Charger output:
Recharge time from
low-voltage warning:
Degree of protection of drive:
Degree of protection of hand control:
Sound power level:
The label (for example, fig. 11) provides important
information:
1 Conformance code
2 Duty cycle
3 Disposal instructions
4 Degree of protection
5 Serial number
6 Day of production
7 Last digits of year of production
8 Type B application unit
9 Instruction (observe accompanying documents)
10 Period of production
11 Rated voltage/consumption
12 Load capacity
13 Device description
The label is on the rear side of the backrest.
4
920 mm
Remove the hand control and always disassemble the
650 mm
bathlift into two sections for transport (the seat and the
1075 mm
backrest).
24 V DC, 135 mA, 3 VA

Transport

Important!
The backrest is not locked on the seat

when it is folded together.
Do not remove the suction cups when

transporting the bathlift.
The hand control must be removed from

the backrest for transport.
590 mm
715 mm
420 mm
60 mm
420 mm
360 mm
8°
295 mm
135 kg
170 kg
12.1 kg
7.5 kg
4.6 kg
0.43 kg
0.1 kg
< 5 N
14 V
4 A
LiIon
230-240 V AC, 50 Hz
approx. 4 h
IP 66W
IP 67
52 dB(A)
EN
