Item Description
1 Case Front Welded Assembly
2A Control Panel Assembly
2B Thread Forming Screw
3 Insulator
4A Thread Forming Screw
4B 1/4 Plain Washer
4C Lock Washer
4D 1/4-20 Hex Nut
5A Output Terminal
5B Thread Forming Screw
5C Output Terminal Stud Nut
8 220V Receptacle
9 Plain Washer
11 Self Tapping Screw
12 LED Lens, Clear
13 Rubber "O" Ring
14 MOV Assembly
15A Resistor
15B Resistor Mounting Bracket Set
15C Thread Forming Screw
15D 1/4 Plain Washer
15E Lock Washer
15F #10-24 Hex Nut
16A Cover Plate
16B Thread Forming Screw
17A Adapter Plate
17B Self Tapping Screw
19 Plug Button
20 Plug Button
21 Plug Housing (Not Shown)
22 Locking Post (Not Shown)
Figure B
Figure B: Case Front Assembly
Part Number
L11890
L11889
S9225-61
S21094-1
S9225-66
S9262-98
E106A-2
CF000017
S16656-4
S9225-63
T3960
S19654-1
S9262-3
S80025-76
S23093-1
S23094-1
S19457-2
S10404-122
T15137-1
S9225-63
S9262-27
E106A-1
CF000010
S21150-1
S9225-61
S25610
S8025-96
T10397-20
T10397-23
S24017-6
S24019-6
99
QTY 1 2 3 4
1 X
1 X
8 X
1 X
1 X
3 X
2 X
2 X
2 X
4 X
2 X
1 X
4 X
4 X
2 X
2 X
1 X
1 X
1 X
2 X
2 X
2 X
2 X
2 X
4 X
1 X
2 X
1 X
1 X
1 X
1 X
