REVERSING THE DOOR SWING
REHANG THE FREEZER DOOR
12
Lower the freezer door onto the center hinge pin.
Center Hinge Pin
Lift the top hinge so the pin fits into the door socket.
Support the door on the handle side and make sure
the door is straight and the gap between the doors is
even across the front. While holding the door in
place, tighten the top hinge screws.
To avoid scratching the corner cap, adjust the
bottom hinge pin so that there is a 1/16" (1.5 mm)
gap between the door stop and the top of the door
corner cap.
Reinstall the top hinge cover.
Installation Instructions
1/16"
(1.5 mm)
Gap
30
(CONT.)
