Notice d'utilisation Fcontrol Basic – variateurs de la séries FSDM3..50(A)M
11.2.2
Branch Circuit Protecteion (BCP)
For 100 kA: class RK5 fuses
Suitable For Use On A Circuit Capable Of Delivering Not More Than 100 kA rms Symmetrical
Amperes, 480 Volts Maximum when protected by Class RK5 Fuses.
Model
FSDM3
FSDM5
FSDM8
FSDM10
FSDM16
FSDM20
For 5 kA: Class RK5 fuses
Suitable For Use On A Circuit Capable Of Delivering Not More Than 5 kA rms Symmetrical Amperes,
480 Volts Maximum when protected by Class RK5 Fuses.
Model
FSDM25
FSDM32
For 30 kA: Special Purpose fuses
Suitable For Use On A Circuit Capable Of Delivering Not More Than 30 kA rms Symmetrical Amperes,
480 Volts Maximum when protected by Special - purpose Fuse (JFHR2/8).
Manufacturer SIBA
Cat.no. 50 124 06, rated 700 Vac, 50 A SCCR 200 kA
Model
FSDM25
FSDM32
The voltage rating of the external fuses shall be at least equal to the input voltage of the drives.
For 100 kA: Special Purpose fuses
Suitable For Use On A Circuit Capable Of Delivering Not More Than 30 kA rms Symmetrical Amperes,
480 Volts Maximum when protected by Special - purpose Fuse (JFHR2/8).
Manufacturer SIBA
Cat.no. 20 189 20, rated 700 Vac, 80 A SCCR 200 kA
Alternative Mersen cat. no. DN000UB69V80 rated 700 Vac, 80 A, SCCR 200 kA
Alternative Eaton Bussmann cat. no. 170M1366 rated 700 Vac, 80 A, SCCR 200 kA
Model
FSDM40
FSDM50
L-BAL-E317-F 2025/13 Index 006
Input Voltage [Vac]
3 x 200 - 415 V
3 x 415 - 480 V
3 x 200 - 415 V
3 x 415 - 480 V
3 x 200 - 415 V
3 x 415 - 480 V
3 x 200 - 415 V
3 x 415 - 480 V
3 x 200 - 415 V
3 x 415 - 480 V
3 x 200 - 415 V
3 x 415 - 480 V
Input Voltage [Vac]
3 x 200 - 415 V
3 x 415 - 480 V
3 x 200 - 415 V
3 x 415 - 480 V
Input Voltage [Vac]
3 x 200 - 415 V
3 x 415 - 480 V
3 x 200 - 415 V
3 x 415 - 480 V
Input Voltage [Vac]
3 x 200 - 415 V
3 x 415 - 480 V
3 x 200 - 415 V
3 x 415 - 480 V
maximum Fuse size [Aac]
15 A
15 A
15 A
15 A
20 A
20 A
25 A
25 A
25 A
25 A
40 A
40 A
maximum Fuse size [Aac]
40 A
40 A
40 A
40 A
maximum Fuse size [Aac]
50 A
50 A
50 A
50 A
maximum Fuse size [Aac]
80 A
80 A
80 A
80 A
Art.N°.
59/64
