USE RANGE
A. OPERATION:
This machine can only work in the vertical position.
After you choose the desired working position, put the material to be bending
between rollers. in order to get the desired bending act upon the leading roller in
the bending direction by hand. The desired profile bending is obtained by turning
the upright driving shaft of slide war gradually, as well as the position of the main
roller shaft. The guiding rollers are driven by the bending mechanism activated by
the electric motor. It allows repeated travels in both directions.
Starting of the electric motor in the both direction is made using the double pedal.
B. Standard and Optional rollers:
The Round bending machine RBM50 is used for bending steel profiles got
by rolling. The machine is equipped with a set of standard rollers used for
bending profiles of parallelepipedal section. For other type of profiles there
are special set of rollers, we can make with customers special requirement.
MAINTENANCE
Clean, grease and make the necessary adjustments before each operation.
Check the temperature of bearings (touching them by hand) during operation. The
temperature must not exceed 50°.

ELECTRIC INSTALLATION

A. Technical conditions
1) Supply with electrical power is made according to EN 60204-1,4.3. The
machine is wired up to a three-phase supply network, equipped with working
earthing (PE). The feed circuit will be protected against short-circuit and
amperages exceeding the permitted values.
2) Electric installation is made under lP44 protection degree.
3) Electric installation works under the following conditions:
