VEVOR RBM50 Mode D'emploi page 14

Part # Description
1 Check ring
2 Bearing
3 Check ring
4 Gear
5 Key
6 Shaft
7 Bolt
8 Reducer
9 Motor
10 Nut
11 Pressure Pad
12 Roller
13 Adjusting gasket
14 Protecting cover
15 Conical bearing
16 Bearing bushing
17 Key
18 Key
19 Shaft
20 Check ring
21 Gear
22 Check ring
23 Bearing bushing
24 Conical bearing
25 Nut
Q'ty Part #
1 35
1 36
1 37
1 38
1 39
1 40
4 41
1 42
1 43
3 44
3 45
2 46
3 47
3 49
2 50
2 51
2 52
2 53
2 54
2 56
2 57
2 58
2 59
4 60
3 61
- 13 -
Description
Key
Gear
Frame
Washer
Bolt
Screw
Bolt
Rotating shaft stand
Shaft
Rotating shaft
Rotating shaft cover
Screw
Cover
Plate
Screw
Screw
Washer
Nut
Screw Rod
Rod
Handle ball
Screw
Pallet
Pin roll
Spring
Q'ty
1
4
1
6
6
4
4
4
4
2
2
3
1
4
12
4
4
1
1
1
2
4
1
1
1
