Operation mode
Line Mode
Battery Mode
INFOSEC UPS SYSTEM - 15, rue du Moulin - 44880 Sautron - FRANCE - www.infosec-ups.com Hot Line –
Tel + 33 (0)2 40 76 15 82 - Fax + 33 (0)2 40 94 29 51 - hotline@infosec.fr – 10 24 AA 59 203 08
Description
The unit will provide output
power from the mains. It will
also charge the battery at
line mode.
The unit will provide output
power from battery and PV
power.
LCD display
If "solar first" is selected as output source
priority and battery is not connected, solar
energy and the utility will provide the loads.
Power from utility.
Power from battery and PV energy.
PV energy will supply power to the loads and
charge battery at the same time.
Power from battery only.
Power from PV energy only.
55
