5. OPERATION
Power ON/OFF
Press On/Off switch on the top of the case to turn on the unit. At this time, the unit will have AC output power.
If only requires the USB port with DC output, you can turn off the inverter to save the power consumption
and extend the backup time for the USB port. (Explain how?)
Battery BMS ON/OFF
BMS switch is to wake up or shut down the battery module inside the unit.
If battery module is off, press and hold the button (located in the rear panel of the unit) over 5 seconds
-
to turn on the battery module.
If battery module is working, press and hold the button for 5 seconds to shut down the battery module.
-
* If the unit is connected with either AC or PV inputs, the unit will wake up the internal BMS automatically, no
need to press this BMS ON/OFF button.
Battery Status LEDs: Indicates battery module status.
LED Color
Green
Orange
Red
INFOSEC UPS SYSTEM - 15, rue du Moulin - 44880 Sautron - FRANCE - www.infosec-ups.com Hot Line –
Tel + 33 (0)2 40 76 15 82 - Fax + 33 (0)2 40 94 29 51 - hotline@infosec.fr – 10 24 AA 59 203 08
Battery Status
On
There is output from battery module.
Standby
BMS is working but no output from battery
Fault
Fault condition in battery module.
Messages
43
