Charger source priority:
16
To configure charger
source priority
18
Alarm control
Auto return to default
19
display screen
20
Backlight control
Beeps while primary source
22
is interrupted
Overload bypass:
When enabled, the unit will
23
transfer to line mode if
overload occurs in battery
mode.
25
Record Fault code
29
Low Battery cut-off point
INFOSEC UPS SYSTEM - 15, rue du Moulin - 44880 Sautron - FRANCE - www.infosec-ups.com Hot Line –
Tel + 33 (0)2 40 76 15 82 - Fax + 33 (0)2 40 94 29 51 - hotline@infosec.fr – 10 24 AA 59 203 08
If this inverter/charger is working in Line, Standby or Fault mode,
charger source can be programmed as below:
Solar first
Solar and Utility (default)
Only Solar
If this inverter/charger is working in Battery mode, only solar
energy can charge battery. Solar energy will charge battery if it's
available and sufficient.
Alarm on (default)
Return to default display
screen (default)
Stay at latest screen
Backlight on (default)
Alarm on (default)
Bypass disable (default)
Record enable (default)
SOC 10% (default)
Solar energy will charge battery as
first priority.
Utility will charge battery only
when solar energy is not available.
Solar energy and utility will charge
battery at the same time.
Solar energy will be the only
charger source no matter utility is
available or not.
Alarm off
If selected, no matter how users
switch display screen, it will
automatically return to default
display screen (Input voltage
/output voltage) after no button is
pressed for 1 minute.
If selected, the display screen will
stay at latest screen user finally
switches.
Backlight off
Alarm off
Bypass enable
Record disable
Adjustable range is from 10% to
50%. Increment of each click is
1%.
49
