Display Setting
The LCD display information will be switched in turns by pressing "UP" or "DOWN" key. The selectable information
is switched as following order in listed table.
Selectable information
Input voltage/Output voltage
(Default Display Screen)
Input frequency
PV voltage
PV current
PV power
50
INFOSEC UPS SYSTEM - 15, rue du Moulin - 44880 Sautron - FRANCE - www.infosec-ups.com Hot Line –
Tel + 33 (0)2 40 76 15 82 - Fax + 33 (0)2 40 94 29 51 - hotline@infosec.fr – 10 24 AA 59 203 08
LCD display
Input Voltage=230V, output voltage=230V
Input frequency=50Hz
PV voltage=260V
PV current = 2.5A
PV power = 500W
