In battery mode, it will present battery capacity.
Working Mode
Battery mode
Load Information
Mode Operation Information
Mute Operation
46
INFOSEC UPS SYSTEM - 15, rue du Moulin - 44880 Sautron - FRANCE - www.infosec-ups.com Hot Line –
Tel + 33 (0)2 40 76 15 82 - Fax + 33 (0)2 40 94 29 51 - hotline@infosec.fr – 10 24 AA 59 203 08
Battery Voltage
<25% SOC
25% ~ 50% SOC
50% ~ 75% SOC
> 75% SOC
Indicates overload.
Indicates the load level by 0-24%, 25-49%, 50-74% and 75-100%.
0%~24%
Indicates unit connects to the mains.
Indicates unit connects to the PV panel.
Indicates load is supplied by utility power.
Indicates the utility charger circuit is working.
Indicates the DC/AC inverter circuit is working.
Indicates unit alarm is disabled.
LCD Display
25%~49%
50%~74%
75%~100%
