Encoder slowdown
Activate the opening and closing slowdown starting points.
[ENCODER]
This function appears only
if the [ENCODER] parameter is
activated from the [Confi g] function
Opening slowdown point for M1
Set the opening slowdown starting point for M1 (percentage of the total travel).
This function appears only if the [Enc. Slow.] function is active.
[ENCODER]
This function appears only
if the [ENCODER] parameter is
activated from the [Confi g] function
Closing slowdown point for M1
Set the closing slowdown starting point for M1 (percentage of the total travel).
This function appears only if the [Enc. Slow.] function is active.
[ENCODER]
This function appears only
if the [ENCODER] parameter is
activated from the [Confi g] function
Opening slowdown point for M2
Set the opening slowdown starting point for M2 (percentage of the total travel).
This function appears only if the [Enc. Slow.] function is active.
[ENCODER]
This function appears only
if the [ENCODER] parameter is
activated from the [Confi g] function
Closing slowdown point for M2
Set the closing slowdown starting point for M2 (percentage of the total travel).
This function appears only if the [Enc. Slow.] function is active.
[ENCODER]
This function appears only
if the [ENCODER] parameter is
activated from the [Confi g] function
Closing approach point for M1
Set the closing approach starting point for M1 (percentage of the total travel).
[ENCODER]
This function appears only
if the [ENCODER] parameter is
activated from the [Confi g] function
[Enc. Slow.]
[M1 Slow. OP. %]
[M1 Slow. CL %]
[M2 Slow. OP.%]
[M2 Slow. CL. %]
[M1 Appr. CL. %]
[ON] (Default)
[OFF]
From 1% to 60% (Default 10%)
From 1% to 60% (Default 10%)
From 1% to 60% (Default 10%)
From 1% to 60% (Default 10%)
From 1% to 15% (Default 15%)
