Closing thrust
When the leaves reach the closing limit-switch, the operator performs a closing thrust for a few seconds.
[FUNCTIONS]
Lock
Associate the electric lock release with a command.
[FUNCTIONS]
Confi gurations
Confi gure slowdowns and limit switches.
[Slow.] and [Op.LS-Cl.Slow.] must be confi gured with the [Slow. T.].
[FUNCTIONS]
Limit switch
Confi gure the limit switch contacts as NO or NC.
This function only appears when one of the follow parameters is selected from the [Confi g] function: [Limit
switch] [Op.LS-Cl.Slow.] [Slow.].
[FUNCTIONS]
Command 2-7
Associate a command with the device connected to 2-7.
[FUNCTIONS]
Command 2-3P
Associate a command to the connected device on 2-3P.
[FUNCTIONS]
[Cl. thrust]
[Lock]
[Confi g]
[Limit switch]
[Command 2-7]
[Command 2-3P]
[Deactivated] (Default)
[Activated]
[Deactivated] (Default)
[Close]
[Open]
[Open-Close]
[Slow.] = Slowdown during opening and closing
[Op.LS-Cl.Slow.] = Opening limit-switch and closing
slowdown.
[ENCODER] = Encoder (Default)
[Time LS] = Time limit switch
[Limit switch] = Opening and closing limit-switches
[N.C.] (Default)
[N.O.]
[Open-Close](Default)
[Op. Stop Cl.]
[Partial]
The degree of opening of the leaf is set with the
[Part. open] function in the [SET TIME] menu.
[Pedestrian] (Default)
