Command and control devices
STOP button (NC contact)
1
This stops the gate and excludes automatic closing. Use a control device to resume movement.
If the contact is not used, it must be deactivated during programming.
Control device (NO contact)
2
OPEN ONLY function
When the [HOLD-TO-RUN] function is active, the control device must be connected during OPENING.
Control device (NO contact)
3
PARTIAL OPENING function
PEDESTRIAN OPENING function
See Command 2-3P function.
4 Control device (NO contact)
CLOSE ONLY function
When the [HOLD-TO-RUN] function is active, the control device must be connected during CLOSING.
5 Control device (NO contact)
OPEN-CLOSE function
OPEN-STOP-CLOSE-STOP function.
See control function 2-7.
6 Card reader
7 Transponder selector switch
8 Keypad selector
9 Antenna with RG58 cable
10 11 ES TS 1 2 3 3P 4 5 7 CX CY CZ S1 GND A B
