Designation
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
Infrared receiver
USB connection (DC 5 V, 1 A)
Display
CD tray
On/standby
MODE/Source selection
MENU (device menu)
PRESET (favourites memory)
OK/Confirm
Open/close CD tray (Eject)
Headphone connection (stereo jack 3.5 mm)
INFO
SCAN /
(channel scan, play/pause)
BACK /
(Back, Stop, Decouple)
TUNING
Volume +/- rotary control
DAB+/FM antenna connection or antenna
OPTICAL IN (Digital Optical)
AUX IN (analogue audio stereo jack 3.5mm)
LINE IN 1 (analogue cinch R/L)
LINE IN 2 (analogue cinch R/L)
LINE OUT (analogue cinch R/L)
SUB OUT (analogue cinch mono)
W-LAN antenna connection
Speaker connections (min. 4 Ohm)
Mains cable
