Evolution R210 CMS Instructions D'origine page 4

MACHINE SPECIFICATIONS
MACHINE
Motor (230-240V ~ 50 Hz)
Motor (110V ~ 50 Hz)
Speed No Load
Weight (Net)
Dust Port Diameter
Tool Dimensions (H x W x L) (0° / 0°)
(Note: Dimensions taken with saw head down.)
Cable Length
CUTTING CAPACITIES
Mild Steel Plate - Max Thickness
Mild Steel Box Section - Max Wall Thickness
(50mm mild steel box section.)
Wood – Max section
Minimum size work-piece
(Note: Any workpiece smaller than the recommended minimum
workpiece requires additional support before cutting.)
MAXIMUM CUTTING ANGLES
Mitre
Bevel
MITRE
0°
0°
45°
45°
BLADE DIMENSIONS
Diameter
Bore
Thickness
NOISE DATA
Sound Pressure L A (No-Load)
P
Sound Power Level L A (No-Load)
W
Uncertainty, K & K
pA WA
> The maximum permissible system impedance Zmax at the interface point of the user's supply is 0,238Ω. The user shall
determine in consultation with the supply authority, if necessary, that the equipment is connected only to a supply of that
impedance or less.
METRIC
1200W
1200W
3750 min
5.8 kg
35mm
260 x 393 x 381mm
2m
METRIC
6mm
4mm
125 x 55mm
L:178 x W:20 x D:3mm
LEFT
50˚ at 0˚ Bevel
50˚ at 45˚ Bevel
0˚ - 45˚
MAX WIDTH
BEVEL
OF CUT
0° 125mm (4-15/16 In.)
45° 125mm (4-15/16 In.)
0° 85mm (3-3/8 In.)
45° 85mm (3-3/8 In.)
METRIC
210mm
25.4mm
1.7mm
110v: 96.02dB / 230v: 97.14dB
110v: 109.02dB / 230v: 110.14dB
4
www.evolutionpowertools.com
IMPERIAL
5A
11A
3750 min
-1 -1
12.8 lb
1-3/8 In.
10-15⁄64 x
15-15⁄32 x 15 In.
6ft 9⁄16 In.
IMPERIAL
1/4 In.
5/32 In.
4-15/16 x 2-3/16 In.
7 In.
RIGHT
50˚ at 0˚ - 20˚ Bevel
45˚ at 21˚- 45˚ Bevel
N/A
MAX DEPTH
OF CUT
55mm (2-3/16 In.)
35mm (1-3/8 In.)
55mm (2-3/16 In.)
35mm (1-3/8 In.)
IMPERIAL
8-1/4 In.
1 In.
1/16 In.
3 dB(A)
