IMPORTANT
If you have ordered a SPO12 Wide Lift (5W0/7W0/10W0 Series) these figures
MUST be used in place of the standard instruction figures on pages 7 & 8.
Standard Height = 12'-11-1/2"
Extended Height 1 = 13'-11-1/2"
Extended Height 2 = 14'-11-1/2"
WARNING
depression due to fire or explosion risks.
1 Phase Lifts
(2)3/8"-16NC x 3/4" HHCS & Flanged Locknut
2 Spacers
1/4"-20NC x 2-3/4" HHCS
& 1/4" Locknut
SPO12 Wide Supplement Instructions
Overhead Assembly
3/8"-16NCx3/4" HHCS
Tie Bar & Spacers -use
(2)3/8"-16NCx 2-1/2"
And Flanged Lock Nuts
Use (2) 3/8"-16NCx1"
DO NOT install this lift in a pit or
Mounting
Bracket
& Flanged Locknut
Carriage Bolts
Carriage Bolts
In Front And
(2) In the Back
Fig. 2
(4)3/8"-16NC x 1" Flanged HHCS and Flanged Nuts
1/4"-20NC x 2-3/4" HHCS,
Flat Washer, Spacer, and Nut
131"
5
Star
Washer
11-3/4"
This Side
Spacer
Fig. 6
