6 DIMENSIONS
6.1 SP4M
12345678
M6x1‐6H
35
6‐M6x1‐6H,
16 deep
19.1
* SP4M.../1 kg: 18 mm
SP4M, SP4Mi
DIMENSIONS
Load direction
M6x0.5, 16 deep
99.6
150
Cover with ATEX, Zone 1 and 21;
Zone 2 and 22 (31 mm x 25 mm)
x4
SP4C3‐MR 20kg
v
year
week
Cable and plug (see chapter 4
"Electrical connection", page 8)
34
19.1
6.1
Dimensions in mm (1 mm = 0.03937 inches)
Round cable 3000"50 mm
51
