You can also teach-in the switching points, as described for the Smart Sensor profile.
For this process, the menu contains the "Teach" subitem.
First select which switching signal channel you want to teach in. Select "Teach SP1" or
"Teach SP2" to specify the switching point with the mass that is currently being
measured.
With the single point method, you only have to teach-in SP1; the hysteresis is entered
(see above).
When using the two point or Windows functionality, both switching points must be taught-
in. You can enter a hysteresis for the range monitoring (window).
Index
Subindex
(hex)
(hex)
0x003A
0x00
0x003B
0x00
0x0002
0x00
5.5.3
Additional information ("Diagnostics")
Under this menu item you can read out additional measured values:
S
Supply Voltage
You will still have access to statistical information that is not permanently saved.
S
Number of IO-LINK connection breaks (IO-Link reconnections)
S
Processor load
S
Operating hours since startup (device uptime)
The following information is permanently stored and can be read out:
SP4M, SP4Mi
IO-LINK OPTION (SP4Mi)
R/W
Data
Explanation
type
RW
U8
SSC1_2 Config
(logic, mode, hyst)
RW
U8
SSC1_2 logic
RW
U8
SSC1_2 mode
RW
F32
SSC1_2 hyst
R/W
Data
Explanation
type
RW
U8
Teach Select
RO
Result (success or
error)
WO
U8
0x41=Teach SP1;
0x42=Teach SP2
Comments
Access to all of the
configurations for
switching channel 2
Inverted/not inverted
Operating mode
(e.g., two point)
Hysteresis input
Comments
Selection of the switching
channel
Confirmation that the teach
process is OK
Triggering the tech
process
