sigfox ANALOG - Guide utilisateur / User guide version V2.0.0

1.4. Technical Specifications

1.4.1

General characteristics

Settings
Supply voltage
Power supply
FR
Maximum Power
Working temperature
Dimensions
Weight
Casing
EN
Radio standards
1.4.2

Autonomy

Operating conditions
Product shelf life before
use: Maximum 1 year.
Calculations performed at a
temperature of 20°C
The above values are estimations based on certain conditions of use and environment. They do not represent a commitment on the part of
adeunis®.
1.4.3

Physical interface characteristics

1.4.3.01 4-20mA interfaces
The schematic diagram of the 4-20mA interfaces is the following:
Absolute maximum values
Minimum input current
Maximum input current
Caractéristiques électriques
Minimum input current
Maximum input current
Equivalent input impedance
12-bit analog input resolution
Values higher than the absolute maxima would damage the product.
Value
Nominal 3.6V
Removable battery version: SAFT LS14500
90mA
-25°C / +70°C
105 x 50 x 27mm
70g
IP 67
EN 300-220, EN 301-489, EN 60950
Sending periodicity
140 frame/day
100 frame/day
50 frame/day
20 frame/day
10 frame/day
2 frame/day
0
30
4
20
99,8 (+/-0,1%)
Autonomy
4 month
6 month
11 month
2.3 years
4.2 years
13.6 years
Units
mA
mA
Unité
mA
mA
Ω
Page 52 of 86
