4 Adjustments
Quick-release Seat Clamp
❶ Unlock the quick-release lever. Figure 4.19
❷ Adjust the seat height up or down until the rider feels they
have control of the bicycle and are comfortable.
Important! Be sure the minimum insertion marks do not go
past the top of the seat clamp and are not visible. See
Section 1, Fig. 1.2: Seat Height and Handlebar Reach.
❸ Close the quick-release lever and lock the seat in place.
If there is not enough pressure to hold the seat in place
open the quick-release lever. With one hand on the quick-
release lever and one hand on the adjustment nut, start to
hand tighten the adjustment nut until you start to feel some
resistance against the fork. Do not attempt to tighten by
turning the quick-release lever. The quick-release lever is for
closing, the adjustment nut is for adjusting the pressure.
Figure 4.20
❹ Try to close the quick-release lever. If it closes easily, open it
up and tighten the adjustment nut further. If it is too
difficult to close, open the quick-release lever, loosen the
adjustment nut a little and try again.
Important! You should feel resistance when you close
the quick-release lever that should leave a temporary
impression on your fingers. Open and close the handle to
ensure the seat is securely locked in place.
38
Seat post
2
Adjustment nut
Quick-release
lever
3
Quick-release
seat clamp
1
Figure 4.19
Minimum
insertion
marks
Figure 4.20
